产品详情
|
代 号
|
螺纹 E
|
软 管 HOSE BORE
|
尺寸 DIMENSIONS
|
|
PART NO.
|
THREAD E
|
公称内径 DN
|
标号 DASH
|
L
|
H
|
S1
|
|
20791-12-04
|
M12X1.5
|
6
|
04
|
32
|
29
|
17
|
|
20791-14-04
|
M14X1.5
|
6
|
04
|
30
|
30
|
17
|
|
20791-14-05
|
M14X1.5
|
8
|
05
|
32.5
|
32.5
|
19
|
|
20791-14-06
|
M14X1.5
|
10
|
06
|
36.5
|
38.5
|
19
|
|
20791-16-04T
|
M16X1.5
|
6
|
04
|
32
|
32.5
|
19
|
|
20791-16-05T
|
M16X1.5
|
8
|
05
|
32.5
|
30.5
|
19
|
|
20791-16-06
|
M16X1.5
|
10
|
06
|
36.5
|
39.5
|
22
|
|
20791-18-05T
|
M18X1.5
|
8
|
05
|
32.5
|
38.5
|
22
|
|
20791-18-06T
|
M18X1.5
|
10
|
06
|
36.5
|
36
|
22
|
|
20791-22-08T
|
M22X1.5
|
13
|
08
|
43.5
|
43.5
|
27
|
|
20791-27-08T
|
M27X1.5
|
13
|
08
|
44.5
|
48.5
|
32
|
|
20791-27-10T
|
M27X1.5
|
16
|
10
|
55
|
49.5
|
32
|
|
20791-30-10T
|
M30X1.5
|
16
|
10
|
55
|
54
|
36
|
|
20791-30-12
|
M30X1.5
|
19
|
12
|
64
|
62
|
36
|
|
20791-33-12T
|
M33X2
|
19
|
12
|
62
|
61
|
41
|
|
20791-36-12T
|
M36X2
|
19
|
12
|
62
|
57
|
41
|
|
20791-36-14T
|
M36X2
|
22
|
14
|
68.5
|
63
|
41
|
|
20791-36-16T
|
M36X2
|
25
|
16
|
74
|
64
|
41
|
|
20791-39-16T
|
M39X2
|
25
|
16
|
74
|
66
|
46
|
|
20791-45-20T
|
M45X2
|
32
|
20
|
91.5
|
78.5
|
55
|
|
20791-52-24T
|
M52X2
|
38
|
24
|
108
|
92
|
60
|
注：1.表中代号用于编织软管。2.如需要用于缠绕软管代号改为20792-XX-XX。
NOTE:1.For use with braided hoses.2.If use spiral hoses,hose fitting series number is 20792-XX-XX.
